SD型 橡胶减振垫产品重要特点与用途
SD型橡胶减振垫采用优质橡胶为材料，有圆形四陷镂空、剪切瓦楞形。一般以剪切形受力为主，具有固有频率低、结构简单、使用方便。为了提高减振效果可将减振垫适合二层、三层、四层串联使用。适用于水泵、风机、压缩机、冷水机组、柴油机组等机械设备消极减振。
产品尺寸：170mm*70mm*20mm 150mm*150mm*20mm 120mm*120mm*20mm 50m*50mm*20mm
SD/JDF type rubber damping pad
Characteristics and use of products
SD type rubber shock pad is made of high quality rubber as the material, there is a circular depression, corruga ted hollow shear. In general, shear force, has low natural frequency, simple structure, easy to use. In order to improve the damping effect of the damping pad for two layer, three layer, four layer series. Suitable for water pump, fan, compressor, chiller, diesel and other mechanical equipment of negative damping.
Product size: 170mm*70mm*20mm 150mm*150mm*20mm 120mm*120mm*20mm 50m*50mm*20mm
